4 manufacturer photos · 1 / 4
Ortur · Diode
Ortur Laser Master 3 · 10W
Budget LM3: engraving-focused open-frame diode
All Ortur models →Add to compare →
Last updated How we evaluate
Released August 2022
Choose a power option
Details below update for the selected power option.
Showing specs for: 10W
TL;DR
The 10W Laser Master 3 is Ortur's lower-power SKU on the same frame. Ideal for learning and engraving; cutters should choose the 20W version.
Best for
What makes this machine stand out
Hardware and workflow features worth understanding before you buy : not just wattage on a label.
LM3 platform at entry price
$299.99 for the basic set in October 2026, with the same LM3 frame and controller as the costlier version.
Full 400 × 400 mm bed
Ortur lists the full 400 × 400 mm area for this module, slightly larger than with the stronger head.
Our verdict
Ideal if you
Ortur Laser Master 3 10W suits makers who sell marks, photos, and gifts more than daily panel cutting. Reasonable open-frame entry price.
Skip if you
Skip if you already quote 5 mm+ cutting in production: see 20W in the line. Not for cast acrylic or bare metal without spray.
Pros
- Basic set at $299.99 on Ortur's store in October 2026, less than half the price of the stronger LM3
- Full 400 × 400 mm working area, per Ortur
- Wi-Fi and USB control on the LM3 platform
Cons
- Photo fills of ~20–42 mm/s: a 10 × 10 cm photo takes ~15–23 min
- Cutting slows to ~2–3 mm/s on 3 mm wood
- Ortur only advertises the free Air Pump 1.0 with the higher-power LM3 set
What this machine is for
High-quality hobby and light-business engraving with light, slow cutting
10W module · Ortur Laser Master 3
Laser spot size
~0.09 mm spot
Motion precision: 0.01 mm
Sample engrave job
~15–23 min
10 × 10 cm (4 × 4 in)
Sample cut job
~8–12 min
10 × 10 cm (4 × 4 in)
Reference benchmark: same job size on every machine so you can compare times fairly. Times are estimates for the reference job above; your design complexity and settings will change them.
Materials
- · Wood
- · Leather
- · Slate
- · Anodized aluminum
- · Stainless (with spray)
Accessories & add-ons
Typical inclusions and add-ons for this profile : confirm your SKU.
- Optional
Enclosure / cabinet
Third-party enclosure improves smoke control and safety
- Recommended
Laser safety glasses
~450 nm diode: OD rated for your wavelength
- Recommended
Fire extinguisher
Editorial guidance : not a live parts list. See also: Ventilation setup · Safety basics
Practical notes
Beginner notes
This profile is the 10W SKU on Ortur Laser Master 3. Read the TL;DR and benchmarks above, then compare other power options via the chips before buying.
Pro tips
Run material test grids at engraving speeds first. Add air assist for light cuts. If cut jobs exceed ~30% of your week, open the higher-watt profile on this site and compare times.
Pro / technical specsRaw numbers for experienced users comparing machines.
- Max speed (spec)
- 333 mm/s
- Avg engrave speed
- 20–42 mm/s fill
- Avg cut speed
- 2–3 mm/s on 3 mm wood
Common questions
How much does the LM3 10W cost compared with the 20W?
On Ortur's store in October 2026 the LM3 10W basic set was $299.99 and the 20W basic set $639.99, the latter with a free Air Pump 1.0. Both sit inside our tracked $140–1,740 range, which spans used units up to Ortur's all-in-one bundles.
What can the LM3 10W cut?
In our benchmarks a 10 × 10 cm square in 3 mm basswood takes about 8–12 min at 2–3 mm/s. Basswood up to about 5 mm and thin black acrylic are possible in several passes. Ortur publishes one-pass cutting demos only for the 20W module.
LM3 10W or 20W: which one suits me?
Take the 10W for engraving-led work on a budget: it keeps the full 400 × 400 mm area, while Ortur lists 400 × 380 mm for the 20W. Take the 20W if you cut regularly: it handles our 3 mm square in about 5–8 min and Ortur demonstrates 10 mm plywood in one pass, for roughly $340 more.
