Ortur · Diode
Ortur Laser Master H10 · 40W
Unofficial 40W pairing on the H10 frame: Ortur sells this machine with 10W or 20W only
All Ortur models →Add to compare →
Last updated How we evaluate
Released September 2024
Choose a power option
Details below update for the selected power option.
Showing specs for: 40W
TL;DR
Ortur does not sell an H10 40W: its H10 page offers 10W and 20W modules only, and the separate LU3-40A 40W module is listed for the LM3 and F10, not the H10. This profile covers listings that pair the H10 frame with a 40W module. Treat it as an unofficial configuration and get the seller to confirm compatibility and warranty in writing.
Best for
What makes this machine stand out
Hardware and workflow features worth understanding before you buy : not just wattage on a label.
Fastest H10 cutting
3 mm basswood squares in about 6–10 min in our benchmark profile, with cut speeds up to ~12 mm/s.
Quick fills
Roughly 80–180 mm/s on photo and logo fills, the fastest of the H10 profiles on this site.
Our verdict
Ideal if you
Ortur Laser Master H10 40W targets mixed engraving and wood-cutting weeks: fewer passes on basswood and dark acrylic than weaker SKUs in the same line.
Skip if you
Wrong pick if you never engrave and only wanted the lowest price. Ultra-fine photo work can look better on an engraving-first SKU. Open-frame: safety and smoke are on you.
Pros
- Fastest fills of the H10 profiles we list: ~80–180 mm/s
- Cuts 3 mm basswood squares in ~6–10 min in our benchmarks
- Handles basswood up to about 10 mm in multiple passes
Cons
- Ortur's H10 page does not list a 40W module: confirm compatibility and warranty with the seller
- Heavier smoke and charring: air assist and ducted exhaust are mandatory
- Highest price of the H10 range: $649–899 on our tracked listings
What this machine is for
Maximum cut speed and depth in the line: engraving remains strong at tuned speeds
Unofficial 40W pairing · Ortur Laser Master H10
Laser spot size
~0.08 mm spot
Motion precision: 0.01 mm
Sample engrave job
~12–18 min
10 × 10 cm (4 × 4 in)
Sample cut job
~6–10 min
10 × 10 cm (4 × 4 in)
Reference benchmark: same job size on every machine so you can compare times fairly. Times are estimates for the reference job above; your design complexity and settings will change them.
Materials
- · Wood
- · Leather
- · Slate
- · Anodized aluminum
- · Stainless (with spray)
Accessories & add-ons
Typical inclusions and add-ons for this profile : confirm your SKU.
- Optional
Enclosure / cabinet
Third-party enclosure improves smoke control and safety
- Recommended
Laser safety glasses
~450 nm diode: OD rated for your wavelength
- Recommended
Fire extinguisher
Editorial guidance : not a live parts list. See also: Ventilation setup · Safety basics
Practical notes
Beginner notes
This profile covers an unofficial 40W configuration: Ortur sells the H10 with 10W or 20W modules only. Read the FAQ below, then compare the official 10W and 20W profiles via the chips before buying.
Pro tips
Treat engraving and cutting as separate profiles. Push cut speeds only after test squares on your material. Compare CO₂ only when clear acrylic or all-day production enters the picture.
Pro / technical specsRaw numbers for experienced users comparing machines.
- Max speed (spec)
- 333 mm/s
- Avg engrave speed
- 80–180 mm/s fill
- Avg cut speed
- 4–12 mm/s on 3–6 mm wood
Common questions
Does Ortur actually sell an H10 40W?
Not as a listed configuration: Ortur's H10 page offers only 10W and 20W modules, and its compatibility list does not include the separate LU3-40A 40W module. A listing sold as an H10 40W is likely a reseller pairing; ask the seller to confirm the module and that it is supported on the H10 frame before buying.
What would a 40W module cut on this frame?
In our benchmark profile a 10 × 10 cm square in 3 mm basswood takes about 6–10 min at 4–12 mm/s. Basswood up to about 10 mm and dark acrylic up to about 5 mm are realistic in several passes with air assist. Clear acrylic stays out of reach.
40W or the supported 20W H10?
On our tracked listings the 40W costs $649–899 against $499–699 for the 20W. It is only worth it if you cut 6 mm and more every day. The 20W comes with a free air pump from Ortur and is the officially supported configuration, which matters for warranty and spare parts.
