Sculpfun · Diode
Sculpfun iCube Pro Max · 10W
10W Compact enclosed Sculpfun: small footprint, full safety cabinet
All Sculpfun models →Add to compare →
Last updated How we evaluate
Released April 2024
Choose a power option
Details below update for the selected power option.
Showing specs for: 10W
TL;DR
Sculpfun iCube Pro Max 10W is the 10W SKU on the Sculpfun sculpfun icube pro line. Sculpfun's enclosed desktop laser for makers who want the brand's cutting performance in a safer cabinet. Verify optical power on the listing: do not assume combined-watt marketing.
Best for
What makes this machine stand out
Hardware and workflow features worth understanding before you buy : not just wattage on a label.
Real light cutting in a compact unit
3 mm basswood squares in about 6–10 min in our benchmarks, rare for a machine this small.
Quick small batches
Fills of roughly 75–160 mm/s make series of tags, coasters and keychains fast.
LightBurn bundle available
Sculpfun sells a version with a LightBurn Core licence key, handy if you plan to work in LightBurn from day one.
Our verdict
Ideal if you
Sculpfun iCube Pro Max 10W suits makers who sell marks, photos, and gifts more than daily panel cutting. Enclosed format is easier to live with at home.
Skip if you
Skip if you already quote 5 mm+ cutting in production. Not for cast acrylic or bare metal without spray.
Pros
- Cuts 3 mm basswood about twice as fast as the lower-power iCube in our benchmarks
- Filled engraving at ~75–160 mm/s: coasters and tags finish quickly
- Same compact footprint, smoke filtration and eye shield as the rest of the iCube range
Cons
- Wider 0.08 mm focus: very small text is slightly softer than on the finest iCube
- Long cutting runs produce more smoke than the built-in filter handles comfortably
- Small working area caps panel size whatever the laser power
What this machine is for
High-quality hobby and light-business engraving with light, slow cutting
10W module · Sculpfun iCube Pro Max
Laser spot size
~0.08 mm spot
Motion precision: 0.01 mm
Sample engrave job
~12–18 min
10 × 10 cm (4 × 4 in)
Sample cut job
~6–10 min
10 × 10 cm (4 × 4 in)
Reference benchmark: same job size on every machine so you can compare times fairly. Times are estimates for the reference job above; your design complexity and settings will change them.
Materials
- · Wood
- · Leather
- · Slate
- · Anodized aluminum
Accessories & add-ons
Typical inclusions and add-ons for this profile : confirm your SKU.
- Included
Enclosure / cabinet
- Optional
Laser safety glasses
Still useful when servicing or with lid open
- Recommended
Fire extinguisher
Editorial guidance : not a live parts list. See also: Ventilation setup · Safety basics
Practical notes
Beginner notes
This profile is the 10W SKU on Sculpfun iCube Pro Max. Read the TL;DR and benchmarks above, then compare other power options via the chips before buying.
Pro tips
Run material test grids at engraving speeds first. Add air assist for light cuts. If cut jobs exceed ~30% of your week, open the higher-watt profile on this site and compare times.
Pro / technical specsRaw numbers for experienced users comparing machines.
- Max speed (spec)
- 167 mm/s
- Avg engrave speed
- 75–160 mm/s fill
- Avg cut speed
- 4–12 mm/s on 3 mm wood
Common questions
Is the iCube Pro 10W the same as the iCube Pro Max?
Yes. Sculpfun sells the 10W version as the iCube Pro Max: a 10W diode with a 0.08 mm focus and the same 10,000 mm/min maximum speed as the 5W model. Sculpfun also sells it in a bundle with a LightBurn Core licence key, so compare bundles before comparing prices.
How thick can the iCube Pro 10W cut?
In our benchmarks a 10 × 10 cm square in 3 mm basswood takes about 6–10 min at 4–12 mm/s. Basswood up to about 5 mm is realistic in a few passes, thin black acrylic works, clear acrylic does not. The small bed is the bigger limit for cut projects.
When is the 10W worth it over the iCube Pro 5W?
As soon as cutting is more than occasional: it roughly halves 3 mm cut times (6–10 min against 9–15 min) and fills faster, for about $100–150 more on our tracked listings. If you only engrave small text and photos, the 5W's finer 0.06 mm focus is a real argument.
